Century® 9722 MultiFit® Condenser Fan Motor

Century® MultiFit® Condenser Fan Motor ✔ 3 jaar beperkte garantie ✔ Topkwaliteit – Door klanten goedgekeurd 🛒 Bestel de jouwe vandaag nog!

• Replaces Hundreds of 1/6 to 1/4 HP Applications
• All angle mount
• Class B insulation
• Reversing plug
• Totally enclosed
• 36 inch leads
• 60C ambient
• Single speed
• Multi-mounting system
• Double sealed ball bearings
• Energy efficient PSC design
• One makkelijk connection eliminates the need to select various horsepower or change capacitor sizes

• H.P. -1/4,1/5-1/6
• Speeds 1
• Amps 2.00-1.20-1.00
• Rotation Reversible
• Capacitor POC7.5
• RPM 1075 – 1145 – 1165
• Bearings Ball
• Diameter (In.) 5
• Enclosure Totally Enclosed
• Mounting Stud or Belly Band
• Service Factor 1.00
• Shaft Length (In.) 3
• Motor Type Permanent Split Capacitor
• Frame 42
• Overload Automatic
• Phase 1
• Shaft Diameter (In.) 1/2
• Shafts 1
• Hertz 60
• Shaft Dimension (In.) 1/2
